Sardine Pressure Retort Autoclave Sterilizer Pouch Retort Machine | Ready to Eat Food Retort Industrial Machine

•

• Advantages of sterilization pot：


• High Productivity: The machine is designed to provide high efficiency and low cost, making it an ideal choice for manufacturing plants, food shops, and food & beverage shops looking to increase their production capacity.

• Advanced Sterilization Technology: Equipped with an automatic control system and water-bath retort, this machine ensures thorough sterilization of food products, meeting the highest standards of food safety.

• Customizable Options: The machine can be customized to suit specific user needs, with options for 220v/380v power supply and a range of dimensions (700-1200).

• Durable Construction: Made from high-quality stainless steel SUS304, the machine is built to last, with a 5-year warranty on the core components and a 5-year warranty on the entire machine.

• Compliance with Industry Standards: The machine is designed to meet the requirements of various industries, including manufacturing plants, food shops, and food & beverage shops, and comes with a machinery test report and video outgoing-inspection for added assurance.

        Product parameters

Model	Inner diameter(mm)	Length(mm)	Capacity（m³）	Temperature（℃）	Pressure（Mpa）	Voltage(V）	Power（kw）
SC.1010.B.3	1000	1000	1.05	145	0.3	380	6
SC.1020.B.3	1000	2000	1.80	145	0.3	380	9
SC.1220.B.3	1200	2000	2.65	145	0.3	380	14
SC.1230.B.3	1200	3000	3.74	145	0.3	380	17.5
SC.1236B.3	1200	4000	4.06	145	0.3	380	19.5
SC.1430.B.3	1300	4000	5.62	145	0.3	380	23

1 .water bath retort is composed of two tanks. Hot water store in tank and temperature preset. Soft water with recycle work to save energy and water resource.
2 .water retort using circulate water and continuous steam supply ensure the temperature error within 5° for all bathed products.
3 water retort temperature of circulating water is uniformly and stable under the dual function of top tank preheating, circulation pump and steam.

4 We will recommend the size that suits you based on the production volume of your product
